- Medical Electrical Safety Testers
92108 Leakage Current Meter
Model:92108
● The 92108 is a handy universal tester for checking electrical appliances.
● Appliance leakage current measurement
● Four functions : DC current, AC current, AC+DC current and ACV measurement.
Details
AC/DC Leakage Current Meter
Model:92108
The 92108 is a handy universal tester for checking electrical appliances.
It's used for:
Motor operated appliances : washing machine, electrical pump, lawn mower, refrigerator, electric drill, electric fan, vending machine.
Electrothermal appliances : toaster, electric stove, electric curling iron, hair dryer.
Electronic appliances : projector, duplicator and photographic enlarger.
Other appliances : portable generator, burglar alarm, medical and dental equipment.
Features:
● High quality Taut Band movement.
● Four functions : DC current, AC current, AC+DC current and ACV measurement.
● Three input resistance ranges : 1KΩ, 1.5KΩ and 2KΩ.
● 200uA full scale value.
● ±2.5% full scale value accuracy.
● Built-in overload protection circuit.
● Robust, compact and easy to carry.
● Meets : IEC/EN61010-1 CAT. III 600V, EN61326-1
Technical Data:
|
Range
|
|
|
DC Current
|
0.1-1-10 mA
|
|
AC Current
|
0.1-1-10 mA
|
|
AC+DC Current
|
0.1-1-10 mA
|
|
AC Voltage
|
150 - 300V (50/60 Hz)
|
|
Accuracy
|
±2.5% of full scale value
|
|
Input Impedance
|
|
|
Current Ranges
|
1KΩ, 1.5KΩ and 2KΩ
|
|
Voltage Ranges
|
150V/500KΩ, 300V/1MΩ
|
|
Working Frequency
|
20Hz ~ 5kHz
|
|
Overload Protection
|
With stands 30mA AC for 10 minutes
for each current measuring rang
|
|
Operating Temperature
|
0°C ~ 50°C
|
|
Operating Humidity
|
Max. 80% R.H.
|
|
Power supply
|
8 x 1.5V, IEC LR6
|
|
Dimensions
|
210 x 210 x 100 mm
|
|
Weight Approx.
|
1.4kg (battery included)
|
Scope of Supply:
1 pc AC/DC Leakage Meter 92108
8 pc Battery 1.5V, type IEC LR6
2 pc Test Leads (red/black)
1 pc Instruction Manual
