92751 BEHATEST Digital Insulation Tester

Model:92751
Price:0US$

● Three insulation test voltages (DC V) : 250V, 500V, 1000V.
● Automatic circuit discharge.
● Test insulation at rated voltage into a 1mA load.
● 200mA resistance tests short circuit test current.
● AC voltage measurement.
 Details



BEHATEST Megohmmeter

1kV Digital Insulation Tester/

Model: 92751


About Insulation:
Every electrical apparatus and installation need to be safe for the user and for the equipment itself.
Electrical conductors of electricity need to be insulated from each other, so that they do not create electrical hazard or unnecessary consumption.
Badly insulated circuits can create leakage current which can be dangerous and trip your RCD, GFCI, RCCB or ELCB.
Each country regulate those levels at which the insulation is acceptable.
Generally, Insulation resistance measurements are done between each conductor and the earth, and between each conductors.
About Continuity:
Checking the continuity of wires, complete circuits, connections, closure of contacts, circuit breakers, fuses, bounding resistance of connections, etc... Are all very important.

Features:
● 68 x 34mm (1.338" x 2.677") large LCD display.
● Three insulation test voltages (DC V) : 250V, 500V, 1000V.
● External voltage warning indication.
● Automatic circuit discharge.
● Test insulation at rated voltage into a 1mA load.
● 200mA resistance tests short circuit test current.
● AC voltage measurement.
● Fuse protection.
● Timer for test function (count 3~5 minutes).
● Data hold function.
● Auto power off function.
● IEC/EN 61010-1/ BS 16th edition/ CAT III 600V.

Technical Data:
Display
3 1/2 digit; LCD; 1999 Digits
Insulation

Test Voltage
250V/500V/1000V
Auto-Ranges
0-20MΩ/0-200MΩ/0-2000MΩ
Accuracy
20MΩ: ±(1.5%rdg+5dgt)
200MΩ: ±(2.5%rdg+3dgt)
2000MΩ: ±(5%rdg+5dgt)
AC Voltage

Measuring Ranges/ Resolution
0-600V/1V
Line Frequency Range
40-120Hz
Accuracy
±(1.5%rdg+3dgt)
Continuity

Measuring Range(Auto)
0-20/0-200/0-2000Ω
Open Circuit Terminal Voltage
4V/DC
Shot Circuit Terminal Current
200mA/DC
Accuracy
±(1.5%rdg+3dgt)
Buzzer Sounds under
10MΩ
General

Power supply
6 x 1.5 V, IEC LR6
Safety complying with
IEC 61010/ BS 16th edition
Measurement category
CAT III/600 V
Dimension
205 x 90 x 55mm
Weight
approx. 550g (battery included)

Scope of Supply:
1 pc Insulation Tester 92751
2 pc Test leads With Crocodile Clamps
6 pc Batteries 1.5 V, IEC LR6
1 pc Instruction Manual
