- Voltage Tester
90050 Voltage and Continuity Tester
Model:90050
● Voltage test : 12V, 24V, 50V, 127V, 230V, 400V, 690V/AC/DC
● Continuity test : 6kΩ, 60kΩ, 300KΩ
● Probe Distance : 19mm apart
Details
Voltage and Continuity Tester
Model: 90050
Voltage test : 12V, 24V, 50V, 127V, 230V, 400V, 690V/AC/DC
Continuity test : 6kΩ, 60kΩ, 300KΩ
Probe Distance : 19mm apart
Features:
● Voltage test : 12 to 690V AC/DC (7 LEDs) with indication by buzzer.
● Voltage range : 12V, 24V, 50V, 127V, 230V, 400V, 690V.
● Resistance range : 6kΩ, 60kΩ, 300kΩ.
● Test leads positioned at 19mm apart.
● Polarity test : LED ±
● Audible continuity test
● Self-test button to ensure proper function of the device prior to testing.
● Integrated storage clips for test probe.
● Rubberized injection molding.
Features:
● Voltage test : 12 to 690V AC/DC (7 LEDs) with indication by buzzer.
● Voltage range : 12V, 24V, 50V, 127V, 230V, 400V, 690V.
● Resistance range : 6kΩ, 60kΩ, 300kΩ.
● Test leads positioned at 19mm apart.
● Polarity test : LED ±
● Audible continuity test
● Self-test button to ensure proper function of the device prior to testing.
● Integrated storage clips for test probe.
● Rubberized injection molding.
Technical Data:
|
Display
|
9 LEDs
|
|
Voltage Test
|
12 to 690V AC/DC
|
|
Voltage Range
|
12V, 24V, 50V, 127V, 230V, 400V, 690V
|
|
Working Frequency
|
0 to 400 Hz
|
|
Voltage Protection
|
1000V DC / 700V AC
|
|
Continuity Range
|
6kΩ
|
|
Resistance Range
|
6kΩ, 60kΩ, 300kΩ
|
|
Operating Temperature
|
0 to 40℃
|
|
Operating Humidity
|
80% RH
|
|
Probe Distance
|
19mm apart
|
|
Power Supply
|
1 x 9 V, IEC 6LR 61
|
|
Dimensions (mm)
|
260 x 58 x 42 mm
|
|
Weight
|
Approx. 210g (battery included)
|
|
Electrical Safety
|
IEC 61010-1 CAT III 600V, IEC 61243-3
|
Scope of Supply:
1 pc Voltage and Continuity Tester 90050
1 pc Battery 9V, IEC 6LR61
1 pc Carrying Case
1 pc Instruction Manual
