3001 Voltage Tester

Model:3001

• Voltage Tester 3001

• AC/DC Voltage Measurement up to 690V

• Continuity test function with optical and acoustical indication up to 200 kΩ

• Integrated single pole test for phase detection

• Automatic AC/DC voltage measurement selection

Details

Voltage Tester

Model: 3001

Features

• AC/DC Voltage Measurement up to 690V

• Continuity test function with optical and acoustical indication up to 200 kΩ

• Integrated single pole test for phase detection

• Automatic AC/DC voltage measurement selection

• Bright LED display

• Fully operational voltage display even when batteries are discharged or when no batteries are fitted

• Rugged, ergonomically formed housing for perfect handling

• Quick single hand test on 19 mm contact distance outlets

• Probe-tip protection for reducing the danger of injuries which may caused by probe-tips

Technical data

Display	10 LED (+12V, -12V, 24V, 50V, 120V, 230V, 400V, 690V, Single Pole, Continuity)
Voltage Range	12…690 V
Polarity Indication	automatic
Frequency Range	DC, 0…65 Hz
Test Current	< 3.5 mA
Single Pole Voltage Test	100...690 V AC
Continuity/Diode Test	optical / acoustical
Measurement Cat	CAT III / 600 V
Pollutin Degree	2
Protection Degree	IP 54
Safety	EN 61010, EN 61243-3
Power Supply	Batteries 2 x 1.5 V, IEC LR03/ AAA
Dimension	approx. 205 x 67 x 27 mm
Weight	approx. 130 g

Scope of Supply:

1 pc Voltage and Continuity Tester 3001

2 pc Batteries 1.5V, IEC LR03

1 pc Instruction manual
