- Voltage Tester
90015 Contact-free Voltage Tester
Model:90015
● Voltage detection : 50V~1000V/AC
● Flash light function.
● ON/OFF switch for longer battery life
Details
Contact-free Voltage Tester
Model: 90015
The non-contact Voltage Detector is intended to check for the presence of AC Voltage, signaling the user with an intermittent tone and a flashing LED.
They are used to detect voltage in outlets, lighting fixtures, circuit breakers, wires, and cables or to find a break in a wire.
Voltage detection : 50V~1000V AC
ON/OFF switch for longer battery life
Features:
● Bright LED and audible alarm sound when voltage is present.
● Designed for non-contact voltage detection. It's safer.
● Can be used to find a break in a wire.
● Flash light function.
● ON/OFF switch for longer battery life.
● EN 61010-1 / EN 61326-1 / CAT III 600V
Technical Data:
|
Voltage detection
|
50V~1000V AC
|
|
Frequency
|
50~500 Hz
|
|
Indication
|
LED and Tone
|
|
Operating Conditions
|
Temperature : 0~40°C
Humidity : Less than 80% R.H.
|
|
Altitude
|
2000m maximum
|
|
Pollution degree
|
2
|
|
Measurement category
|
CAT III 600V
|
|
Power Supply
|
2 x 1.5 V, IEC LR03
|
|
Dimension
|
142 x 28 x 27 mm
|
|
Weight
|
45g (batteries included)
|
Scope of Supply:
1 pc Non-contact Voltage Detector 90015
2 pc Batteries 1,5 V, IEC LR03
1 pc Instruction Manual
